Stainless Steel 304L Pipes
At ASC LLP we pride ourselves on offering premium quality materials to meet diverse industrial requirements. Among our extensive product range, 304L stainless steel plates stand out due to their exceptional properties and versatile applications. This page aims to provide a comprehensive overview of 304L stainless steel plates, detailing their properties, material composition, and common uses.
What is 304L Stainless Steel Plate?
304L stainless steel plates are a low-carbon variation of the standard 304 stainless steel. The “L” in 304L stands for “low carbon,” which implies a maximum carbon content of 0.03%. This slight difference significantly enhances the material’s weldability and reduces the risk of carbide precipitation during welding. As a result, 304L grade stainless steel plates are widely used in applications where welding is required without compromising corrosion resistance.
Properties of 304L Stainless Steel Plates
Understanding the 304L stainless steel plates properties is crucial for selecting the right material for your project. Here are the key properties that make 304L stainless steel plates an excellent choice:
- Corrosion Resistance: One of the primary advantages of 304L stainless steel plates is their excellent corrosion resistance. This material is resistant to a wide range of corrosive environments, including acidic and chloride-containing atmospheres.
- Weldability: Due to its low carbon content, 304L stainless steel plates offer superior weldability compared to other stainless steel grades. This property makes them ideal for fabrications that require extensive welding.
- Formability: 304L stainless steel plates are known for their good formability. They can be easily formed into various shapes and sizes without compromising their structural integrity.
- Strength and Durability: Despite the lower carbon content, stainless steel 304L plates retain excellent strength and durability, making them suitable for both heavy-duty and lightweight applications.
- Temperature Resistance: These plates can withstand high temperatures, which makes them suitable for applications involving heat exposure.
Material Composition of 304L Stainless Steel Plates
The 304L stainless steel plates material is composed of the following elements:
- Chromium (Cr): 18-20%
- Nickel (Ni): 8-12%
- Carbon (C): Max 0.03%
- Manganese (Mn): Max 2%
- Silicon (Si): Max 0.75%
- Phosphorus (P): Max 0.045%
- Sulfur (S): Max 0.03%
Advantages of Using 304L Stainless Steel Plates
Choosing 304L stainless steel plates for your project offers several benefits:
- Cost-Effective: The durability and low maintenance requirements of 304L stainless steel plates make them a cost-effective choice in the long run.
- Environmental Resistance: These plates maintain their structural integrity and appearance in harsh environmental conditions, reducing the need for frequent replacements.
- Versatility: The ability to use 304L stainless steel plates in various applications across multiple industries highlights their versatility.
- Aesthetic Appeal: The smooth, shiny surface of 304L stainless steel plates adds a modern and sophisticated look to any project.
Stainless Steel 304L Plate Schedule and Size Chart
Thickness (mm) | Width (mm) | Length (mm) |
---|---|---|
1.0 – 3.0 | 1000 – 1500 | 2000 – 3000 |
3.1 – 6.0 | 1000 – 2000 | 2000 – 6000 |
6.1 – 12.0 | 1000 – 2000 | 2000 – 6000 |
12.1 – 20.0 | 1000 – 2500 | 2000 – 6000 |
20.1 – 50.0 | 1000 – 2500 | 2000 – 6000 |
Mechanical Properties of 304L Stainless Steel Plates
Property | Metric | Imperial |
---|---|---|
Tensile Strength | 485 MPa | 70 ksi |
Yield Strength | 170 MPa | 25 ksi |
Elongation | 40% | 40% |
Hardness (Brinell) | 123 HB | 123 HB |
Specifications of 304L Stainless Steel Plates
Standard | Specifications |
---|---|
ASTM | A240/A240M |
ASME | SA240/SA240M |
EN | 1.4307 |
JIS | SUS 304L |
UNS | S30403 |
Chemical Composition of 304L Stainless Steel Plates
Element | Composition (%) |
---|---|
Chromium | 18.0 – 20.0 |
Nickel | 8.0 – 12.0 |
Carbon | Max 0.03 |
Manganese | Max 2.0 |
Silicon | Max 1.0 |
Phosphorus | Max 0.045 |
Sulfur | Max 0.03 |
Nitrogen | Max 0.10 |
Iron | Balance |
Applications Chart for 304L Stainless Steel Plates
Industry | Applications |
---|---|
Chemical and Petrochemical | Storage tanks, process vessels, piping systems |
Food and Beverage | Processing tanks, conveyor belts, prep surfaces |
Medical and Pharmaceutical | Surgical instruments, implants, medical devices |
Marine | Boat fittings, shipbuilding, offshore platforms |
Architecture and Construction | Cladding, roofing, structural applications |
Automotive and Aerospace | Exhaust systems, structural components |
Physical Properties Chart for 304L Stainless Steel Plates
Property | Value |
---|---|
Density | 8.0 g/cm³ |
Melting Point | 1398 – 1454 °C |
Specific Heat (0-100°C) | 500 J/kg·K |
Thermal Conductivity | 16.2 W/m·K (at 100°C) |
Electrical Resistivity | 0.072 x 10^-6 Ω·m |
Modulus of Elasticity | 193 GPa |
Poisson’s Ratio | 0.27 – 0.30 |
Why Choose ASC LLP for 304L Stainless Steel Plates?
ASC LLP is a trusted name in the industry, known for providing top-notch stainless steel products. When you choose us for your 304L stainless steel plate needs, you benefit from:
- Quality Assurance: We adhere to stringent quality control measures to ensure that our 304L stainless steel plates meet the highest standards of quality and performance.
- Expertise: With years of experience in the industry, we have the expertise to understand your specific requirements and provide tailored solutions.
- Wide Range of Products: We offer a comprehensive range of 304L stainless steel plates in various sizes and specifications to meet diverse industrial needs.
- Competitive Pricing: At ASC LLP, we strive to offer competitive prices for our high-quality 304L stainless steel plates. Our pricing is transparent and based on the current market conditions, ensuring that our clients receive the best value for their investment.
- Customer Support: We are committed to providing excellent customer support. Our team is always ready to assist you with any queries or concerns.
304L stainless steel plates are a reliable choice for various industrial applications due to their exceptional properties, including corrosion resistance, weldability, and durability. At ASC LLP, we offer high-quality 304L stainless steel plates that meet the diverse needs of our clients. With our expertise, quality assurance, and competitive pricing, we are your trusted partner for all your stainless steel plate requirements. Contact us today to learn more about our products and services.
