ST52 Welded Pipes – High-Quality DIN 2391 ST52 Pipes from ASC LLP
Looking for strong, durable, and high-performance ST52 welded pipes? You’ve landed at the right place! ASC LLP is a trusted ST 52.3 Carbon Steel Welded Pipe Supplier, offering top-quality DIN 2391 ST52 Pipe and ST52 Carbon Steel Welded Pipes for various industrial uses. Our pipes are known for their superior strength, smooth surface finish, and long-lasting performance.
What are ST52 Welded Pipes?
ST52 welded pipes are made from ST52 grade carbon steel, a low-alloy, high-strength material that combines excellent toughness with superior weldability. These pipes are manufactured as per the DIN 2391 standard, which ensures precise dimensions and top-tier mechanical properties.
Due to their ability to withstand high pressure and temperature, they are used in various industries, such as construction, automotive, mechanical engineering, oil and gas, and more.
Key Features of DIN 2391 ST52 Welded Pipes
- High tensile strength
- Excellent impact resistance
- Easy to weld and form
- Uniform wall thickness
- Corrosion and wear resistance
- Seamless surface finish
- Cost-effective solution for heavy-duty applications
DIN 2391 ST 52 ERW Pipe – What Makes It Special?
The DIN 2391 ST 52 ERW pipe is made using the Electric Resistance Welding (ERW) process. This method involves welding the pipe edges without filler metal, resulting in a clean and smooth finish.
Benefits of ST52 ERW Pipes:
- Clean internal surface
- Uniform wall thickness
- No weld bead or weak points
- Ideal for hydraulic systems
- Cost-effective for mass production
Whether you’re working on fluid transfer systems or heavy machinery, DIN 2391 ST 52 ERW pipe is a reliable choice.
ST52 Welded Pipes – Schedule and Size Chart (DIN 2391 ST52)
| Nominal Pipe Size (NPS) | Outer Diameter (OD) mm | Wall Thickness Range (mm) | Schedule |
| 1/2″ | 21.3 | 2.77 – 3.73 | SCH 40 / SCH 80 |
| 3/4″ | 26.7 | 2.87 – 3.91 | SCH 40 / SCH 80 |
| 1″ | 33.4 | 3.38 – 4.55 | SCH 40 / SCH 80 |
| 1 1/2″ | 48.3 | 3.68 – 5.08 | SCH 40 / SCH 80 |
| 2″ | 60.3 | 3.91 – 5.54 | SCH 40 / SCH 80 |
| 3″ | 88.9 | 5.49 – 7.62 | SCH 40 / SCH 80 |
| 4″ | 114.3 | 6.02 – 8.56 | SCH 40 / SCH 80 |
| 6″ | 168.3 | 7.11 – 10.97 | SCH 40 / SCH 80 |
| 8″ | 219.1 | 8.18 – 12.70 | SCH 40 / SCH 80 |
| 10″ | 273.0 | 9.27 – 15.09 | SCH 40 / SCH 80 |
| 12″ | 323.8 | 10.31 – 17.48 | SCH 40 / SCH 80 |
ST52 Welded Pipe Sizes and Specifications
| Parameter | Specification |
| Size Range | 1/2” NB to 24” NB |
| Wall Thickness | SCH 20 to SCH 160 / Custom |
| Length | Single Random, Double Random, Cut Length |
| Ends | Plain, Beveled, Threaded |
| Form | Round, Square, Rectangular |
| Surface Finish | Black, Galvanized, Anti-Rust Oil |
DIN 2391 ST52 Pipe – Physical Properties Chart
| Property | Value |
| Density | 7.85 g/cm³ |
| Melting Point | 1420 – 1460 °C |
| Thermal Conductivity | 45 W/m·K at 20°C |
| Electrical Conductivity | 6.99 × 10⁶ S/m |
| Modulus of Elasticity | ~210 GPa |
| Poisson’s Ratio | 0.27 – 0.30 |
| Specific Heat | 470 J/kg·K |
DIN 2391 ST52 Pipe Chemical Composition
| Element | Content (%) |
| Carbon (C) | ≤ 0.22 |
| Manganese (Mn) | ≤ 1.60 |
| Phosphorus (P) | ≤ 0.040 |
| Sulfur (S) | ≤ 0.040 |
DIN 2391 ST52 Welded Pipe Mechanical Properties
| Property | Value |
| Tensile Strength | 600 – 800 MPa |
| Yield Strength | ≥ 355 MPa |
| Elongation | ≥ 22% |
| Impact Resistance | Excellent at -20°C |
| Hardness | Approx. 180 – 220 HB |
Applications of ST52 Carbon Steel Welded Pipe
Our DIN 2391 ST52 welded pipes are highly versatile and ideal for use in:
- Construction – Structural tubing, bridges, and building frameworks
- Automotive industry – Suspension systems, axles, chassis
- Mechanical engineering – Machine components, hydraulic cylinders
- Oil & gas and petrochemical – Pipelines, rigs, and refinery equipment
- Shipbuilding and marine structures
- Cranes and heavy equipment manufacturing
Why Choose ASC LLP as Your ST52 Welded Pipe Supplier?
At ASC LLP, quality and customer satisfaction are our top priorities. Here’s why industries around the world choose us as their ST 52.3 Carbon Steel Welded Pipe Supplier:
- Premium Quality Raw Materials: We source carbon steel from certified mills, ensuring consistent quality and strength.
- Strict Quality Control: All our DIN 2391 ST 52 ERW pipes are tested for dimensional accuracy, pressure handling, and surface finish before dispatch.
- Competitive Prices: We offer the best rates on ST52 Carbon Steel Welded Pipes without compromising on quality.
- Timely Delivery: With a robust logistics network, we ensure fast and safe delivery of your orders globally.
- Custom Sizes and Finishes: Whether you need standard or customized dimensions, we’ve got you covered.
